Premium, next-generation desktop smartphones that deliver breakthrough user experiences.

This phone must be assigned to a user with a unique, directly assigned UniFi Talk phone number and have an Internet connection to function. This phone can share numbers with groups after it is assigned to an eligible user. For configurations where users only share numbers with a group and are not assigned a personal number, use the Phone Touch Max (Unlocked).
Features:
<ul>
<li>Call functions: conference, warm/cold transfer, mute, hold, forward, call waiting, voicemail, internal video calls</li>
<li>Handset, hands-free speakerphone mode, and Bluetooth headset support</li>
<li>UniFi Protect support with on-screen camera streaming and Multi-View grid</li>
<li>Remote door unlocking with UniFi Identity</li>
<li>Powered by PoE+ and connects to a UniFi OS Console via Ethernet or WiFi</li>
</ul>
Notes:
<ul>
<li>A Dream Machine Special Edition, Dream Machine Pro, Dream Router, or Cloud Key Plus is required to run UniFi Talk.</li>
<li>Currently, UniFi Talk is only available in the US and Canada, but we are working on bringing the service to other territories and countries.</li>
</ul>

UVP-TouchMax-LK

Next-generation desktop smartphone with a 5MP camera and a 7" HD color touchscreen, designed for use with a UniFi Talk phone number.

Phone Touch Max

Premium desktop smartphone designed for use with a UniFi Talk phone number.

Default

This unlocked model is ideal for configurations where users only share numbers with groups. We recommend the Phone Touch Max for configurations where each user is directly assigned a unique, personal UniFi Talk phone number.
Features:
<ul>
<li>Call functions: conference, warm/cold transfer, mute, hold, forward, call waiting, voicemail, internal video calls</li>
<li>Handset, hands-free speakerphone mode, and Bluetooth headset support</li>
<li>UniFi Protect support with on-screen camera streaming and Multi-View grid</li>
<li>Remote door unlocking with UniFi Identity</li>
<li>Powered by PoE+ and connects to a UniFi OS Console via Ethernet or WiFi</li>
</ul>
UniFi Talk subscription service is available in Canada as of April 2023. Managed with the UniFi Talk application: Version 1.21.0 and later
Notes:
<ul>
<li>A <a href="https://ca.store.ui.com/ca/en/products/udm-se">Dream Machine Special Edition</a>, <a href="https://ca.store.ui.com/ca/en/products/udm-pro">Dream Machine Pro</a>, <a href="https://ca.store.ui.com/ca/en/products/udr">Dream Router</a>, or <a href="https://ca.store.ui.com/ca/en/products/uck-g2-plus">Cloud Key Plus</a> is required to run <a href="https://ui.com/phone-system">UniFi Talk</a>.</li>
<li>Currently, UniFi Talk is only available in the US and Canada, but we are working on bringing the service to other territories and countries.</li>
</ul>

UTP-TouchMax-U

Color

Black

White

Next-generation desktop smartphone with a 5MP camera and a 7" HD color touchscreen.

Phone Touch Max (Subscription Unlocked)

Premium desktop smartphone that delivers the ultimate user experience.

Mechanical
Dimensions	255 x 135 x 183 mm (10 x 5.3 x 7.2")
Weight	1.52 kg (3.35 lb)
Enclosure materials	Plastic, aluminum (base)
Colour	Black
Display
Display size	178 mm (7") diagonal
Resolution	1280 x 800 HD (16:10)
Screen technology	GFF multi-touch
Video
Camera sensor	5 MP
Resolution	2592 x 1944
Audio
Handset dynamic receiver	16 ohm SPL 116 dB @1KHz, 30mW, 0m
Handset microphone	Omnidirectional electret microphone SNR 70 dB Sensitivity -38 ± 3 dB
Codec	Standalone Hi-Fi audio codec IC Smart speaker amplifier
Hands-free speaker	4 ohm/PNOM 3W, Pmax 5W SPL 79dB @1W, 0.5m
Hands-free microphone	Dual omnidirectional MEMS microphones SNR 64 dB Sensitivity -26 dBFS Digital microphone
Hardware
Processor	Octa-core ARM® Cortex®-A53 at 1.8 GHz
Memory	Storage: 32 GB RAM: 2 GB
WiFi standards	802.11 a/b/g/n/ac
Power input	PoE+
Power output	Type-C port (charging only)
Connectivity	(2) 10/100/1000 MbE RJ45 Bluetooth® 4.2 WiFi 2.4G b/g/n, 20/40 Mhz WiFi 5G a/n/ac, 20/40/80 MHz, Slave DFS
Headset support	3.5 mm (0.14") Audio jack
Operating temperature	0 to 40° C (32 to 104° F)
Operating humidity	10 - 90% noncondensing
Certifications	FCC, IC, CE
Software
LED	Power status: white glowing
Audio DSP algorithm	Active echo cancellation, noise suppression, blind source separation
Protocol	SIP/SDP/RTP/RTCP/VLAN/DHCP
Number of supported phone lines	Multiple
UniFi OS application	UniFi Talk
Minimum software requirements	Web browser (Chrome™ recommended)
