Premium, next-generation desktop smartphones that deliver breakthrough user experiences.

Phone Touch Max
UVP-TouchMax-L
$129.00
Sold Out

7" touch display

Ergonomic handset with mute button

Hi-performance speakerphone

Bluetooth support

PoE+ in

Note. This phone must be assigned to a user with a unique, directly assigned UniFi Talk phone number and have an Internet connection to function. This phone can share numbers with groups after it is assigned to an eligible user. For configurations where users only share numbers with a group and are not assigned a personal number, use the Phone Touch Max (Subscription Unlocked).

To subscribe to back in stock e‑mails.
Phone Touch Max (Subscription Unlocked)
From $299.00
Technical Specifications
Mechanical
Dimensions255 x 135 x 183 mm (10 x 5.3 x 7.2")
Weight1.52 kg (3.35 lb)
Enclosure materialsPlastic, aluminum (base)
ColourBlack
Display
Display size178 mm (7") diagonal
Resolution1280 x 800 HD (16:10)
Screen technologyGFF multi-touch
Video
Camera sensor5 MP
Resolution2592 x 1944
Audio
Handset dynamic receiver16 ohm
SPL 116 dB @1KHz, 30mW, 0m
Handset microphoneOmnidirectional electret microphone
SNR 70 dB
Sensitivity -38 ± 3 dB
CodecStandalone Hi-Fi audio codec IC
Smart speaker amplifier
Hands-free speaker4 ohm/PNOM 3W, Pmax 5W
SPL 79dB @1W, 0.5m
Hands-free microphoneDual omnidirectional MEMS microphones
SNR 64 dB
Sensitivity -26 dBFS
Digital microphone
Hardware
ProcessorOcta-core ARM® Cortex®-A53 at 1.8 GHz
MemoryStorage: 32 GB
RAM: 2 GB
WiFi standards802.11 a/b/g/n/ac
Power inputPoE+
Power outputType-C port (charging only)
Connectivity(2) 10/100/1000 MbE RJ45
Bluetooth® 4.2
WiFi 2.4G b/g/n, 20/40 Mhz
WiFi 5G a/n/ac, 20/40/80 MHz, Slave DFS
Headset support3.5 mm (0.14") Audio jack
Operating temperature0 to 40° C (32 to 104° F)
Operating humidity10 - 90% noncondensing
CertificationsFCC, IC, CE
Software
LEDPower status: white glowing
Audio DSP algorithmActive echo cancellation, noise suppression, blind source separation
ProtocolSIP/SDP/RTP/RTCP/VLAN/DHCP
Number of supported phone linesMultiple
UniFi OS applicationUniFi Talk
Minimum software requirementsWeb browser (Chrome™ recommended)
