airMAX 2.4 GHz, 13 dBi, Omni
AMO-2G13
$245.00
Sold Out
airMAX 2.4 GHz, 13 dBi, Omni
AMO-2G13
$245.00
Sold Out
2.4 GHz, 13 dBi carrier-class 2x2 MIMO omnidirectional antenna designed to seamlessly integrate with Rocket radios.
To subscribe to back in stock emails.
Technical
Dimensions
1390 x 122 x 105 mm
(54.2 x 4.8 x 4.1")
Weight
2.4 kg (5.3 lb)
Wind Survivability
200 km/h (125 mph)
Wind Loading
71.2 N at 160 km/h (16 lbf at 100 mph)
Mounting
Universal Pole Mount, RocketM Bracket, and Weatherproof RF Jumpers Included
Downtilt
2°
Frequency Range
2.35—2.55 GHz
Antenna Gain
13 dBi
Elevation Beamwidth
7°
Max. VSWR
1.7:1
Polarization
Dual-Linear
Cross-Pol Isolation
25 dB min.
ETSI Specification
EN 302 326 DN2 E
NDAA Compliant
✓
